Running PostgreSQL Instances as Containers with Podman

PostgreSQL is a powerful, open-source relational database system widely used in modern applications. Running PostgreSQL as a container offers a range of benefits, particularly when using Podman, a rootless container engine. This post will guide you through the steps to set up PostgreSQL instances using Podman and systemd.

Why Run PostgreSQL as a Container?

Running PostgreSQL as a container has several advantages:

1. Isolation: Each container runs independently, ensuring that libraries and dependencies are isolated from the host system and other containers.
2. Portability: Containers can be easily moved between environments, such as development, staging, and production.
3. Quick Deployment: Starting a new PostgreSQL instance is as simple as running a container, reducing setup time.
4. Simplified Configuration: Containerized PostgreSQL uses environment variables for easy configuration.
5. Rootless Execution: Podman allows running containers without requiring root privileges, enhancing security.

Advantages of Using Podman with Systemd

Integrating Podman containers with systemd adds the following benefits:

1. Automatic Startup: Containers can be configured to start automatically with the system.
2. Service Management: Systemd enables familiar service management commands like start, stop, and status.
3. Reliability: Systemd can restart failed containers automatically.
4. Resource Isolation: With cgroups, systemd can manage resource limits for containers.

Setting Up PostgreSQL as a Container with Podman

Follow these steps to run PostgreSQL instances with Podman and systems. If you are installing Podman for the first time, refer to this guide – Installing Podman on Red Hat Enterprise Linux 9.

Step 1: Pull the PostgreSQL Container Image

The PostgreSQL image from the container registry provides a secure and optimized database engine. Pull the image:

podman pull postgres:latest

Alternatively, you can use the official image registry.redhat.io/rhel8/postgresql-15:latest from Red Hat’s container registry which provides a secure and optimized database engine. Remember, you need to authenticate before pulling an image from Red Hat container registry.

Step 2: Run the First PostgreSQL Container

Alternatively, you can use the podman-compose command to quickly spin up containers with volumes and networks without worrying about command line arguments as shown in the following sections. Refer to the sample podman-compose.yaml file in this repository.

Step 2.1: Create a volume for the PostgreSQL server

If you don’t specify a volume, the PostgreSQL data stored in /var/lib/postgresql/data/ will be lost once the container is stopped or removed. To ensure data persistence, it’s essential to mount a volume for the PostgreSQL data store. You can either use a local directory from your host system or create a dedicated container volume to store the data securely.

Create a container volume as follows.

$ podman volume create postgresapp1
postgresapp1

Step 2.2: Start a PostgreSQL contaner

Create and run the first PostgreSQL instance with the container name postgresql-app1:

Important: Make sure you are using the available ports and not conflicting with the existing port. For example, you can use a custom port such as 5433 or 5434 as the host port to avoid any port conflicts.

$ podman run -d \
  --name postgresql-app1 \
  -e POSTGRES_USER=admin \
  -e POSTGRES_PASSWORD=securepassword \
  -e POSTGRES_DB=appdb \
  -v postgresapp1:/var/lib/pgsql/data:Z \
  -p 5432:5432 \
  postgres:latest

Here:

• 5432:5432 maps the container’s PostgreSQL port to the host.
• postgresapp1 is the container volumes for database storage.
• POSTGRES_DB=appdb is the default database to create. If it is not specified, then the value of POSTGRES_USER will be used.

Step 2.3: Verify the PostgreSQL container

$ podman ps
CONTAINER ID  IMAGE                              COMMAND     CREATED         STATUS         PORTS                             NAMES
cd1ef841bd54  docker.io/library/postgres:latest  postgres    26 seconds ago  Up 26 seconds  0.0.0.0:5432->5432/tcp, 5432/tcp  postgresql-app1

Step 3: Generate a Systemd Service File

Generate a systemd service file for the container:

$ mkdir -p ~/.config/systemd/user
$ podman generate systemd --new --name postgresql-app1 > ~/.config/systemd/user/postgresql-app1.service

Step 4: Enable and Start the Service

Enable and start the systemd service for the container under the specific user:

$ systemctl --user daemon-reload
$ systemctl --user enable postgresql-app1.service
$ systemctl --user start postgresql-app1.service

Verify the status:

$ systemctl --user status postgresql-app1.service

Step 6: Testing systemd service – stop and start PostgreSQL Containers

Let us experiment the systemd service for PostgreSQL – stop and service and check if PostgreSQL container is running.

$ systemctl --user stop postgresql-app1.service
$ podman ps
CONTAINER ID  IMAGE       COMMAND     CREATED     STATUS      PORTS       NAMES

Now, start back the systemd service and verify the if PostgreSQL container is running.

$ systemctl --user start postgresql-app1.service
$ podman ps
CONTAINER ID  IMAGE                              COMMAND     CREATED        STATUS        PORTS                             NAMES
461da94a1801  docker.io/library/postgres:latest  postgres    3 seconds ago  Up 3 seconds  0.0.0.0:5432->5432/tcp, 5432/tcp  postgresql-app1

Step 7: Verify PostgreSQL Instances

Now our PostgreSQL instance should now be running:

Install the psql utility coming with the PostgreSQL package. (You can also use alternative utilities)

$ sudo yum install postgresql

Access the PostgreSQL instance: psql -h localhost -p 5432 -U admin -d appdb

$ psql -h localhost -p 5432 -U admin -d appdb
Password for user admin:<enter the password you used>
psql (13.18, server 17.2 (Debian 17.2-1.pgdg120+1))
WARNING: psql major version 13, server major version 17.
         Some psql features might not work.
Type "help" for help.

appdb=#

Now, you can repeat the steps with different container name, port and sysemd services to run multiple isolated PostgreSQL instances.

Conclusion

Running PostgreSQL as a container using Podman provides portability, isolation, and ease of management. Integrating with systemd further enhances reliability and automation. By following the steps above, you can efficiently run and manage multiple PostgreSQL instances on the same host, leveraging the robust features of Podman and Red Hat’s trusted container images.
